9.5.4 User output protocol (sNuo)
This command modifies the output for the user configured commands. The output can be configured to fit the requirement of an external
display.
A parameter for the output mode between 100 and 189 defines the format for an external display. The last digit of the parameter defines
the field length for the output number. The output of a distance measurement will be right aligned. The decimal point will be inserted at
the position (counted from right) defined by middle digit (See 3.5.2 Output format on page 15).
Set command Get command
Command
sNuo+xxxxxxxx<trm> sNuo
Return successful
gNuo?<trm> gNuo+xxxxxxxx<trm>
Return error
gN@Ezzz<trm> gN@Ezzz<trm>
Parameters
N Device ID
xxxxxxxx Output Mode
0: display distance
1: display additional information
1ab: output formatted for external display
a: Number of digits after decimal point
b: Field with (sign included) must be greater than 0
Conditions: a≤b, if a=b, no decimal point is output.
zzz Error code
Configuration parameters need to be saved (See 9.3.13 Save configuration parameters (sNs) on page 40)
