TECHNICAL REFERENCE MANUAL
9.3.6 Set/Get analog output distance range (sNv)
Sets the minimum and maximum distances corresponding to the minimum and maximum analog output current levels.
0...20mA 4...20mA
Aout Analog current output
DIST Actual measured distance
D
min
Distance programmed for the minimum output current
D
max
Distance programmed for the maximum output current
Set command Get command
Command
sNv+xxxxxxxx+yyyyyyyy<trm> sNv<trm>
Return successful
gNv?<trm> gNv+xxxxxxxx+yyyyyyyy<trm>
Return error
gN@Ezzz<trm> gN@Ezzz<trm>
Parameters
N Device ID
xxxxxxxx Minimum distance in 1/10 mm corresponding to 0mA / 4mA
yyyyyyyy Maximum distance in 1/10 mm corresponding to 20mA
zzz Error code
Configuration parameters need to be saved (See 9.3.13 Save configuration parameters (sNs) on page 40)
Distance Laser Sensor Page 36/53
