9.3.8 Configure digital input (sNDI1)
The digital output 1 of the DLS-C(H)/FLS-C(H) can also be used as digital input. The command sNDI1 configures an action for the device.
The state of the digital input can be read with the command sNRI.
On active digital input, the digital output function of DO1 is deactivated
Set command Get command
Command
sNDI1+xxxxxxxx<trm> sNDI1<trm>
Return successful
gNDI1?<trm> sNDI1+xxxxxxxx<trm>
Return error
gN@Ezzz<trm> gN@Ezzz<trm>
Parameters
N Device ID
xxxxxxxx 0: Digital input inactive (DO1 active)
1: activate the digital input to read out its state with the command
9.3.9 Read digital input (sNRI).
2: Trigger Distance measurement (sNg)
3: Start/Stop Single sensor Tracking (sNh)
4: Start/Stop Tracking with buffering (sNf)
5: Trigger User Distance measurement (sNug)
6: Start/Stop Single sensor User Tracking (sNuh)
7: Start/Stop User Tracking with buffering (sNuf)
8: Start/Stop Single sensor Timed Tracking (sNh+)
1)
9: Start/Stop Single sensor User Timed Tracking (sNuh+)
1)
zzz Error code
1) Uses time for the tracking as set by a previous sNh+ or sNuh+ command
Configuration parameters need to be saved (See 9.3.13 Save configuration parameters (sNs) on page 40)
9.3.9 Read digital input (sNRI)
Displays the state of the digital input, if the input is not inactive. (Necessary configuration of the digital input: sNDI1+1)
Command
Command
sNRI<trm>
Return successful
gNRI+x<trm>
Return error
gN@Ezzz<trm>
Parameters
N Device ID
x 0: Input Off (Signal Low)
1: Input On (Signal High)
zzz Error code
Distance Laser Sensor Page 38/53
