TECHNICAL REFERENCE MANUAL
9.3 Configuration commands
9.3.1 Set communication parameter (sNbr)
Sets the communication parameters for the serial interface.
This command saves all configuration parameters to Flash.
The changed baud rate is activated after the next power on.
Bold = default parameters (first use or after reset)
Command
Command
sNbr+yy<trm>
Return successful
gN?<trm>
Return error
gN@Ezzz<trm>
Parameters
N Device ID
yy Defines the new settings
yy Baud rate Data bits Parity yy Baud Rate Data bit Parity
00 1200 8 N 06 9600 7 E
01 9600 8 N 07 19200 7 E
02 19200 8 N 08 38400 8 N
03 1200 7 E 09 38400 7 E
04 2400 7 E 10 115200 8 N
05 4800 7 E 11 115200 7 E
Distance Laser Sensor Page 33/53
