TECHNICAL REFERENCE MANUAL
9.2 Operation commands
9.2.1 Distance measurement (sNg)
Triggers simple measurement of distance. Each new command cancels an active measurement.
Command
Command
sNg<trm>
Return successful
gNg+xxxxxxxx<trm>
Return error
gN@Ezzz<trm>
Parameters
N Device ID
xxxxxxxx Distance in 1/10 mm
zzz Error code
9.2.2 Single sensor tracking (sNh)
Triggers continuous measurements of the distance. The measurements are made as fast as possible (Measurement speed depends on target
conditions). This command is not to be used with more than one DLS-C(H)/FLS-C(H) on a RS-232/RS-422 line. The measurements are
continued until the STOP/CLEAR command is issued. The status LEDs and the digital outputs are updated corresponding to the new
measured distance.
Never use this command if more than one module is connected to the RS-232/RS-422 line
Command
Command
sNh<trm>
Return successful
gNh+xxxxxxxx<trm>
Return error
gN@Ezzz<trm>
Parameters
N Device ID
xxxxxxxx Distance in 0.1mm
zzz Error code
9.2.3 Single sensor tracking with timer(sNh)
This command does the same as the sNf command, but the unit sends the results directly to the output.
Never use this command if more than one device is connected to the RS-422 line
Command
Command
sNh+xxx<trm>
Return successful
gNh+yyyyyyyy<trm>
Return error
gN@Ezzz<trm>
Parameters
N Device ID
xxx Sampling time in 10ms (if 0 -> use max. possible sample rate)
yyyyyyyy Distance in 0.1mm
zzz Error code
Distance Laser Sensor Page 30/53
