TECHNICAL REFERENCE MANUAL
5.4 Specifications
Typical measuring accuracy for
DLS-C 15 / DLS-CH 15
1)
DLS-C 30 / DLS-CH 30
1)
FLS-C 10 / FLS-CH 10
1,3,4)
FLS-C 30 / FLS-CH 30
1,3)
± 1.5 mm @ 2σ
± 3.0 mm @ 2σ
± 1.0 mm @ 2σ
± 3.0 mm @ 2σ
Accuracy of the analog output
DLS-C(H)
FLS-C(H)
(9.3.6 Set/Get analog output distance range (sNv) on page 36)
0.2% programmed span (12 Bit)
0.1% programmed span (12 Bit)
Typical repeatability for
DLS-C 15 / DLS-CH 15
1)
DLS-C 30 / DLS-CH 30
1)
FLS-C 10 / FLS-CH 10
1)
FLS-C 30 / FLS-CH 30
1)
± 0.4 mm @ 2σ
± 0.5 mm @ 2σ
± 0.3 mm @ 2σ
± 0.5 mm @ 2σ
Smallest unit displayed 0.1 mm
Measuring range on natural surfaces 0.05 m to approx. 65 m (80m on natural surface characteristic
3)
)
Measuring range on orange (reflective) target plate DLS-C(H)
FLS-C(H)
Approx. 25 m to 150 m
Approx. 0.5 m to 500 m
Measuring reference from front edge (See 7 Physical dimensions)
Typical diameter of laser spot at target at a distance of
5)
(diffraction rings)
4mm @ 5m; 8mm @ 10m; 15mm @ 30m
Time for a measurement
Single measurement: DLS-C(H) / FLS-C(H)
3)
Tracking: DLS-C(H)
3)
FLS-C(H)
3)
Typical: 0.3 s to 4 s
Typical: 0.15 s to 4 s
Typical: 4 ms to 4 s
Max target speed while moving target characteristic is active Typical: 10m/s up to 150m
7m/s up to 500m/s
Light source Laser diode 620-690 nm (red)
IEC 60825-1:2007; Class 2
FDA 21CFR 1040.10 and 1040.11
Beam divergence:0.16 x 0.6 mrad
Pulse duration: 0.45x10
-9
s
Maximum radiant power: 0.95 mW
Laser Life Time typical 50'000h @ 20°C (See 4.1.4 Laser Life time consideration on page 17)
ESD IEC 61000-4-2
EMC EN 61000-6-4
EN 61000-6-2
Power supply 9 ... 30V DC 0.6A for DLS-C / FLS-C
24 ... 30V DC 2.5A for DLS-CH /FLS-CH(Heating option)
Dimensions 150 x 80 x 55 mm
Temperature range during operation
2)
DLS-C 15 / DLS-C 30 / FLS-C 10 / FLS-C 30
DLS-CH 15 / DLS-CH 30 / FLS-CH 10 / FLS-CH 30
-10 °C to +50 °C
-40 °C to +50 °C
Temperature range during storage -40 °C to +70 °C
Degree of Protection IP65; IEC60529 (protected against ingress of dust and water)
Weight DLS-C, FLS-C: 690 g
DLS-CH, FLS-CH: 720 g
Standard interface 1 serial asynchronous interface RS-232
1 serial asynchronous interface RS-422
1 SSI (only FLS-C(H))
1 programmable analog output 0/4 .. 20mA
2 programmable digital outputs
1 programmable digital input
1 digital output for error status
1) See 5.1 Measuring accuracy on page 21.
2) In case of permanent continuous measurement (tracking mode) the max. temperature is reduced to 45°C
3) Accuracy and measurement speed depend on configuration (See 9.3.2 Measuring characteristic configuration (sNuc) on page 34)
4) By measuring on the orange reflecting target plate the accuracy may be reduced to ± 1.5 mm @ 2s
5) The spot-size can vary depending on production lot
Distance Laser Sensor Page 23/53
