INSTRUMENT MESSAGES WHILE IN USE
53

Date/time not set: check the  >>  step of the set-up ( ).

It is displayed if one tries to calibrate the zero point without first having confirmed the
number of calibration points.

During the acquisition of a calibration point a null value has been read by the converter.

Selecting the “MASTER” functioning mode this message is show when it’s enabled the
radio and enabled the energy saving mode, it is displayed when the indicator doesn’t
detect the SLAVE for more than 60 seconds.
This message is shown for 3 seconds after that the instrument is turn off.

Calibration error: a too small sample weight has been used; it is advisable to use a weight
equal to at least half of the scale capacity.

Calibration error: the acquired calibration point ( or  or ) is equal to the zero
point ().

The number of converter points per scale division is less than two. Carry out again the
calibration with special attention to the capacity and the division.

It is displayed when the instrument has not yet been calibrated and initialized.
Press the TARE key when the instrument displays “”to enter the technical set-up
environment. Carry out the initialization of the indicator (“”parameter ), and the
selection of the type of keyboard (“”parameter), and finally the programming of all
the parameters of the set-up environment and the calibration.

It is displayed when the instrument has been initialized but not yet been calibrated.
Press the TARE key when the instrument displays “”to enter the technical set-up
environment and carry out the calibration.

During the calibration some internal negative points have been calculated:
- the calibration point is less than the zero point.
- the signal is negative (check the connections)

(blinking)
the weight in underload (i.e. a weight of 100 divisions below the gross zero, if the
instrument is approved) is notified through this message and by an acoustic signal.

(blinking)
the weight in overload (i.e. a weight of 9 divisions greater than the capacity) is notified
through this message and by an acoustic signal.

It is displayed for an instant if the master can connect to the slave X; if the connection is
not possible, the message remains fixed and the master emits an acoustic signal.

Appears when the tilt of the instrument exceeds the 2% for the application on pallet truck
or the 5% for the application on forklift trucks.
The activation of the tilt has a delay of about three seconds from the detection of the
excessive inclination.
