Dini Argeo DGT4X Technical Manual

36
Optimized layout for A4 print.
888888
i
TYPE
A
888888
Setup
C
ConfiG param
1 1
Grav
4
TECH_MAN_ENG_DGT4X
MENU ACCESS:
SAVING THE PARAMETERS:
Press the key during the start-
up procedure.
Press the key several times, until the display shows
SAVE?. Press the key to confirm.
Complete menu
on pages 24 - 25
This parameter allows you to correct the gravity acceleration value.
Before calibration, set the value of the calibration zone.
Next, set this value to the value of the zone of use.
Any dierence between the two values will be automatically compensated.
EXAMPLE:
1. Before calibration, in the GRAV parameter enter the value
9.80390.
2. Calibrate the transmitter.
3. Before using the transmitter, in the GRAV parameter enter the
value 9.77623.
Calibration zone
Italy
g = 9.80390
Zone of use
Brazil
g = 9.77623
In the case of an approved transmitter, the value is read-only.
From 9.75001 to 9.84999.
= 9.80390.
Gravity

Dini Argeo DGT4X Specifications

General

Model	DGT4X
Type	Weight Transmitter
Serial Ports	RS232, RS485
Protocols	Modbus RTU, ASCII
A/D Converter	24-bit
Power Supply	12-24 Vdc
Operating Temperature	-10°C to +40°C
Load Cell Input	Up to 8 load cells (350 Ohm)
Display	6-digit LED
Modulation	GFSK
