54
Optimized layout for A4 print.
i
TECH_MAN_ENG_DGT4X
Serial commands
WEIGHT READING (standard string)
EXTENDED OR MULTISCALE WEIGHT READING
WEIGHT READING IN HIGH RESOLUTION X10 AUTOMATIC TARE
By selecting the PC port on demand mode (onde), you can communicate with the transmitter via serial commands.
For each command received, the transmitter emits a string containing the response (refer to the command description) or one of the following
signals:
OK<CRLF> Command sent when sending a correct command. This response does not imply that the command is executed.
ERR01<CRLF> Command sent correctly but followed by letters entered unintentionally (e.g. READF, TARES).
ERR02<CRLF> Incorrect command data.
ERR03<CRLF> Command sent not allowed (transmitter busy, or not used in the selected operating mode).
ERR04<CRLF> Command sent non-existent.
If the 485 protocol has been selected, you must precede the command with the transmitter address (e.g. 01READ).
Format
R E A D
Format
R E X T
Format
G R 1 0
Format
T A R E
Response
Standard string.
Response
Extended string.
Response
Standard string with weight in resolution x10.
Response
OK (or ERRxx).
MANUAL TARE
Format
T M A N t t t t t t
Where
tttttt tare value
Response
OK (or ERRxx).
ZEROING (of active channel)
Format
Z E R O
Response
OK (or ERRxx).
DISABLING KEYPAD ENABLING KEYPAD
Format
K E Y E D
Format
K E Y E E
Response
OK (or ERRxx).
Response
OK (or ERRxx).
READING INPUTS READING OUTPUTS
Format
I N P U n
Where
n Input (1 / 2).
Format
O U T S n
Where
n Output (1 / 2).
Response
I N P U n v v v v
Where
n Input number.
vvvv
Input status:
0000 = Not active.
0001 = Active.
FFFF = Input reading error.
Response
O U T S n v v v v
Where
n Output number.
vvvv
Output status:
0000 = Not active.
0001 = Active.
FFFF = Output reading error.
By entering a manual tare value of 0, the tare on the
scale is cleared.
