Dini Argeo DGT4X Technical Manual

58
Optimized layout for A4 print.
TECH_MAN_ENG_DGT4X
MODBUS REGISTERS FOR DATA READING MULTISCALE
Data Register DESCRIPTION
Status register
scale 1
40202
Bit 15
(msb)
...
Bit 8
(lsb)
No function.
Bit 7
(msb)
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
(lsb)
Preset tare (0 = “no”; 1 = “yes”).
Active tare (0 = “no”; 1 = “yes”).
Net weight polarity (0 = “+”; 1 = “-”).
Gross zero zone (0 = “outside zone 0”; 1 = “in zone 0”).
Overload condition (0 = No; 1 = overload).
Underload condition (0 = No; 1 = underload).
Stability (0 = “unstable”; 1 = “stable”).
Gross weight sign (0 = “+”; 1 = “-”).
Gross weight
scale 1
40203
Gross weight of scale 1.
40204
Status register
scale 2
40205 As Status register scale 1.
Gross weight
scale 2
40206
Gross weight of scale 2.
40207
Status register
scale 3
40208 As Status register scale 1.
Gross weight
scale 3
40209
Gross weight of scale 3.
40210
Status register
scale 4
40211 As Status register scale 1.
Gross weight
scale 4
40212
Gross weight of scale 4.
40213
Net weight
scale 1
40214
Net weight of scale 1.
40215
Net weight
scale 2
40216
Net weight of scale 2.
40217
Net weight
scale 3
40218
Net weight of scale 3.
40219
Net weight
scale 4
40220
Net weight of scale 4.
40221
This manual contains the main registers for reading data / sending commands.
Refer to the Modbus protocol manual for a complete list of available registers.
