DINO 210XT
21
START-UP
1. Ground stability
- make sure that the ground is even and hard enough to support the lift in a steady level
position
Soil material Density Max. ground
pressure
P kg/cm²
Gravel High density 6
Medium density 4
Loose 2
Sand High density 5
Medium density 3
Loose 1,5
Fine sand High density 4
Medium density 2
Loose 1
Sand/ mud High density (very hard to work) 1,00
Medium density (hard to work) 0,50
Loose (easily worked) 0,25
- if the ground is soft, use sufficiently large and sturdy additional plates under the support
outriggers
- observe the effect of ice, possible rain and inclination of the surface on the support (the
support outriggers must not slip on the surface)
- the operation is prohibited if the lift is not properly supported and in a level position
2. Drive or push the lift to the inspected lifting site
- apply the parking brake
- disconnect the lift from the towing vehicle
