DINO 210XT
94
ELECTRIC COMPONENTS 2945 >
Boom=Boom CH=Chassis DCB=Driving device centre HN=Honda LCB=Chassis control centre
OT=Outrigger PL= Platform RU= Turning device UCB=Platform control centre
ID Diagram Position Part nr. Designation Description of operation
B1 RU 48.2276 Battery Battery
CC1 RU 48.2340 Control card Control card for propo-valve
E1 LCB DL8.058 Thermorelay Thermorelay for electric motor
F1 LCB 48.3030 Fuse 1,6A Control circuit fuse for electric supply
F2 LCB 48.640 Fuse 10A Start circuit fuse
F3 LCB 48.640 Fuse 10A Chassis control centre fuse
F4 LCB 48.3035 Fuse 5A Control switch fuse
F5 LCB 48.3030 Fuse 1.6A Control card fuse
F6 LCB 48.640 Fuse 10A Fuse for solenoid valves
F7 UCB 48.640 Fuse 10A Emergency descent circuit fuse
F8 LCB 48.640 Fuse 10A Control fuse for combustion engine
F9 UCB 48.3030 Fuse 1,6A Joystick fuse
F10 UCB 48.3036 Fuse 5A Platform swing motor fuse
F11 RU 48.3041 Fuse 125A Main battery fuse
F12 LCB 48.3038 Fuse 16A Timer card fuse
H1 UCB 48.2204 LED signal light, green Outreach signal light, inside the range
H2 UCB 48.2203 LED signal light, red Outreach signal light, at the border
H3 LCB 48.2204 LED signal light, green Support outrigger circuit signal light, limit switches closed
H4 LCB 48.2203 LED signal light, red Signal light for safety relay SR3, the safety relay has tripped,
the outreach safety limit switch RK5 has tripped
HM1 LCB 48.3618 Hour meter Hour meter which measures the running time of the engine
J1 CH 48.2085 Socket Plug
JST UCB 4CA9843 Joystick Joystick, operation of the boom
K1 LCB 48.2162 Contactor Control contactor for the electric motor
K2 LCB 48.2162 Contactor Auxiliary relay for emergency stop button
K3 LCB 48.2374 Telescope in K9 Turning of boom, to the left
K4 LCB 48.2374 Telescope in K9 Turning the boom, to the right
K5 LCB 48.2374 Telescope in K9 Lowering the boom
K6 LCB 48.2392 Telescope in K9 Boom down, retardation relay
K7 LCB 48.2374 Telescope in K9 Lifting of the boom
K9 LCB 48.2374 Telescope in K9 Retracting the telescope
K10 LCB 48.2374 Telescope in K9 Extending the telescope
K11 LCB 48.2374 Telescope in K9 Lowering the articulated arms
K12 LCB 48.2392 Telescope in K9 Articulated arms down, retardation
K13 LCB 48.2374 Telescope in K9 Raising the articulated arms
K15 LCB 48.2374 Telescope in K9 Levelling of the platform backward
K16 LCB 48.2374 Telescope in K9 Levelling of the platform forward
K17 LCB 48.2374 Telescope in K9 Activation of the joystick at the centre position
K18 LCB 48.2392 Telescope in K9 Selector relay, platform levelling/chassis control panel
K19 LCB 48.2392 Telescope in K9 Selector relay, control from chassis/platform
K20 LCB 48.2374 Telescope in K9 Blocking relay for the "telescope out" movement
K21 LCB 48.2374 Telescope in K9 Blocking relay for the boom movement
K22 LCB 48.2375 Telescope in K9 Blocking relay for the "telescope out" movement
K23 LCB 48.2374 Telescope in K9 Control of supply voltage to the driving control centre on the
chassis
K24 LCB 48.2375 Telescope in K9 Centre-position activation of joystick
