Dino 210XT - Page 95

DINO 210XT
95
Boom=Boom CH=Chassis DCB=Driving device centre HN=Honda LCB=Chassis control centre
OT=Outrigger PL= Platform RU= Turning device UCB=Platform control centre
ID Diagram Position Part nr. Designation Description of operation
K25 LCB 48.2392 Telescope in K9 Control relay for control card
K26 LCB 48.2374 Telescope in K9 Control relay for combustion engine
speed
K27 LCB 48.2374 Telescope in K9 Control of supply voltage to the driving
control centre on the chassis
K28 LCB 48.2374 Telescope in K9 Control relay for reserve power unit
K29 LCB 48.2374 Telescope in K9 Blocking relay for dual operation,
electric motor/emergency descent motor
K30 LCB 48.2374 Telescope in K9 Control of alternator of the Honda
engine
K31 LCB 48.2374 Telescope in K9 Switch-off of combustion engine
K32 LCB 48.2374 Telescope in K9 Switch-off of combustion engine
K33 LCB 48.2374 Telescope in K9 Relay for optional equipment
K34 LCB 48.2374 Telescope in K9 Blocking relay for re-start if the control
voltage is switched off
K35 LCB 48.2375 Telescope in K9 Blocking relay for re-start if the control
voltage is switched off
K390 LCB 48.2375 Telescope in K9 Change-over relay for secondary
operations of joystick
K391 LCB 48.2375 Telescope in K9 Change-over relay for secondary
operations of joystick
K40 LCB 48.2374 Telescope in K9 Control relay for choke
K41 LCB 48.2133 Telescope in K9 Selector relay, main power
unit/combustion engine
K42 LCB 48.2277 Telescope in K9 Start relay of combustion engine
K50 UCB 48.2374 Telescope in K9 Control relay for the outreach signal
lights
K51 UCB 48.2374 Telescope in K9 Turning the platform, to the left
K52 UCB 48.2374 Telescope in K9
Turning the platform, to the right
M1 RU 47.828 Electric motor AC electric motor
M2 RU 47.2318 Power unit (reserve power
plant)
DC motor for emergency descent
M3 PL 4CB4253 Linear motor Turning motor of the platform.
PL CH 48.3550 Rotary adaptor (electric part) Rotary adaptor, electric transmission
between the chassis and the turning
device
PR UCB 48.2145 Socket outlet socket outlet on the platform 230VAC
16A.
Q1 LCB 48.2316 Turn switch Turn switch with key, choice of
operating location LCB/OK/AK
RK3 CH 48.1936 + 48.2142 Limit switch Limit switch for boom support NC
RK4 Boom 48.2068 + 48.2334 Limit switch Limit switch for outreach control
NC/NO
RK5 Boom 48.2068 + 48.2334 Limit switch Limit switch for outreach control NC
RK7 Boom 48.2116 Limit switch Limit switch for chain NC, opens if the
chain is slack
RK8 Boom 48.1936 + 48.2142 Limit switch Limit switch, telescope fully retracted
NC
RK9 PL 48.2170 Stroke limiter Inductive end limit switch for turning
motor of platform NC
RK10 PL 48.2170 Stroke limiter Inductive end limit switch for turning
motor of platform NC
RK11 OT 48.2413 +48.2414 +48.2415 Limit switch Outrigger limit switch NC, closes as the
outrigger is on the ground
RK12 OT 48.2413 +48.2414 +48.2415 Limit switch Outrigger limit switch NC, closes as the
outrigger is on the ground
RK13 OT 48.2413 +48.2414 +48.2415 Limit switch Outrigger limit switch NC, closes as the
outrigger is on the ground
