DINO 210XT
96
RK14 OT 48.2413 +48.2414 +48.2415 Limit switch Outrigger limit switch NC, closes as the
outrigger is on the ground
S1 LCB 48.2311+48.2313+48.2303 Locking emergency stop button Emergency stop button, NC
S2 LCB 48.2309+48.2312+48.2302 Pushbutton, green Engine start button NO
S3 LCB 48.2310+48.2313 Push button, red Engine stop button NC.
S4 UCB 48.2311+48.2313+48.2303 Locking emergency stop button Emergency stop button, NC
S5 UCB 48.2310+48.2313 Push button, red Engine stop button NC.
Boom=Boom CH=Chassis DCB=Driving device centre HN=Honda LCB=Chassis control centre
OT=Outrigger PL= Platform RU= Turning device UCB=Platform control centre
ID Diagram Position Part nr. Designation Description of operation
S6 UCB 48.2309+48.2312+48.2302 Pushbutton, green Engine start button NO
S10 UCB 48.2309+48.2312 Pushbutton, green Sound signal control button NO.
S11 UCB 48.2335+48.2312 Pushbutton, yellow Emergency descent motor start button
NO, platform
S12 UCB 48.616+48.1007 Lever switch Platform levelling forward/backward,
platform
S13 LCB 48.2335+48.2312 Pushbutton, yellow Emergency descent motor start button
NO, chassis
S16 LCB 48.616 + 48.1007 Lever switch Turning of boom, right/left, chassis
S17 LCB 48.616 + 48.1007 Lever switch Lifting/lowering of the boom, chassis
S18 LCB 48.616 + 48.1007 Lever switch Telescope in/out, chassis
S19 LCB 48.616 + 48.1007 Lever switch Articulated arms down/up, chassis
S20 LCB 48.616 + 48.1007 Lever switch Platform levelling forward/backward,
chassis
S24 DCB 48.616 + 48.1007 Lever switch Drive to the rear
S25 DCB 48.2309+48.2313+48.2303 Pushbutton, green Turning of the chassis
S26 DCB 48.2309+48.2313+48.2303 Pushbutton, green Turning of the chassis
S29 UCB 48.2309+48.2312 Pushbutton, green Dual operation button for levelling of the
platform, platform
S31 UCB 48.2336+48.2312 Pushbutton, blue Retraction of the telescope, is used if the
safety limit switch RK5 has tripped,
platform
S32 LCB 48.2336+48.2312 Pushbutton, blue Retraction of the telescope, is used if the
safety limit switch RK5 has tripped,
chassis
S36 UCB 48.616 + 48.1007 Lever switch Turning of the platform , to left/right,
platform
SR1 RU Solenoid Emergency descent motor solenoid
SR2 LCB 48.2264 Safety relay Support outrigger circuit safety relay, is
active if the outrigger limit switches are
closed
SR3 LCB 48.2264 Safety relay Safety relay for outreach control safety
limit switch, is active if the limit
switches RK4 and RK5 are closed
SR4 LCB 48.2264 Safety relay Safety relay for emergency stop circuit.
Is active provided that the emergency
descent circuit is in order and the RK7 as
well as the K1 and the K2 are not
activated.
SPV RU 48.2442 Mains switch Disconnects the battery from the system
T1 LCB 47.863 Power source Power source, supplies the control
voltage when powered by AC.
T2 RU 48.0125 Battery charger, automatic Battery charger 230VAC 3A
TC LCB 48.3506 Timer card Time card disconnects the power supply
to the lift after a preset delay if the
contactor no longer is active
TR9 LCB Adjustable resistor Adjustment of the levelling speed of the
platform
TR10 LCB Adjustable resistor Adjustment of the lowering speed of the
boom
TR11 LCB Adjustable resistor Universal adjustment of the movement
