DINO 210XT
97
speed when controlling from the chassis
panel.
TR12 LCB Adjustable resistor Speed adjustment of articulated arms
descent
VM1 LCB 48.2063 Voltmeter Voltage meter
VVK CH 48.2287 Fault current switch Fault current switch, switches off the
AC-feed in case of fault current
ÄM1 RU 48.049 Sound signal Sound signal, operation with push button
S10
ÄM2 UCB 48.0108 Sound signal Buzzer, operates if the emergency stop
button is depressed and the safety limit
switch RK5 trips.
Components for Hatz- diesel (Optional)
Boom=Boom CH=Chassis DCB=Driving device centre HN=Honda LCB=Chassis control centre
OT=Outrigger PL= Platform RU= Turning device UCB=Platform control centre
ID Diagram Position Part nr. Designation Description of operation
HZ Linear motor Adsjustment motor of the engine speed
S6 HZ Temperature sensor The switch earths the circuit if the engine
overheats
S7 HZ Oil pressure sensor The switch earths the circuit if the oil
pressure drops
MHZ1 HZ Starter Starter of the diesel engine
Y2 HZ Stop solenoid When the engine is stops, the current
will be switched off and the valve will
close
R1-
GLOW
HZ Glow plug Glow plug of the diesel engine
Components for Honda (Optional)
ID Diagram Position Part nr. Designation Description of operation
S37 HN Pushbutton, green By-pass button for stop circuit of Honda
engine
K4 HN 48.1974 Relay 24V DC Blocking relay for dual starting
IIDA HN 48.2323 Relay Auxiliary relay for switching off
(earthing)
SR4 HN 48.2422 Solenoid Choke solenoid
