Dionex UltiMate 3000 - Direct Injection Onto a Capillary Column; Hardware Layout

UltiMate 3000 RSLCnano – Standard Applications
18
2.5 Direct Injection onto a Capillary Column
2.5.1 Hardware Layout
Figure 12: Setup for a Direct Injection experiment onto a
capillary column
The recommended setup is
presented in Figure 12 and consists
of:
SRD-3400 5035.9245
NCS-3500RS 5041.0020
VWD-3400RS 5074.0010
45 nL flow cell 6074.0280
WPS-3000TPL RS 5826.0020
Application kit: 6720.0305
