UltiMate 3000 RSLCnano – Standard Applications
25
2.7 Pre-concentration onto a 200 µm Monolithic Column
2.7.1 Hardware Layout
Figure 18: Setup for a Pre-concentration experiment onto a
monolithic column
The recommended setup is
presented in Figure 18 and consists
of:
SRD-3400 5035.9245
NCS-3500RS 5041.0020
10-port sw. valve 6041.0001
VWD-3400RS 5074.0010
3 nL flow cell 6074.0270
WPS-3000TPL RS 5826.0020
Application kit: 6720.0320
