UltiMate 3000 RSLCnano – Standard Applications
46
2.12 Tandem nano LC
2.12.1 Hardware Layout
Figure 30: Setup for a Tandem nano LC experiment
The recommended setup is presented in Figure 30
and consists of:
SRD-3400 5035.9245
NCS-3500RS 5041.0010
NCP-3200RS 5041.0030
2x 10-port sw.valve 6041.0001
VWD-3400RS 5074.0010
3 nL flow cell 6074.0270
WPS-3000FC 5824.0020
Application kit: 6720.0335
Tip: The components to
convert the WPS-
3000FC are included in
the application kit.
The NCP-3200RS spare
parts kit has two 130 cm
long solvent inlet tubing
to place the bottles on
top of the system.
