UltiMate 3000 RSLCnano – Standard Applications
29
2.8 Pre-concentration on a Capillary Column
2.8.1 Hardware Layout
Figure 21: Setup for a Pre-concentration experiment onto a
capillary column
The recommended setup is
presented in Figure 21 and consists
of:
SRD-3400 5035.9245
NCS-3500RS 5041.0020
10-port sw. valve 6041.0001
VWD-3400RS 5074.0010
45 nL flow cell 6074.0280
WPS-3000TPL RS 5826.0020
Application kit: 6720.0315
