UltiMate 3000 RSLCnano – Standard Applications
32
2.9 2D Salt Steps with Nano Column
2.9.1 Hardware Layout
Figure 23: Setup for a 2D Salt Plugs experiment
The recommended setup is
presented in Figure 23 and consists
of:
SRD-3400 5035.9245
NCS-3500RS 5041.0010
2x 10-port sw.valve 6041.0001
VWD-3400RS 5074.0010
3 nL flow cell 6074.0270
WPS-3000TPL RS 5826.0020
Application kit: 6720.0325
