UltiMate 3000 RSLCnano – Standard Applications
55
• When using a micro tight union, always use the gauge plug provided with the union to
make sure that the connection is well centered.
PEEK Sleeve (orange)
Nut
Fused Silica Capillary
280 ∝m O.D.
Microt ight
 
Union
Gauge Plug
