dji MATRICE 3D Series Flight Manual

DJI Dock 2/Matrice 3D Series Unmanned Aircraft Flight Manual
100
©
2024 DJI All Rights Reserved.
Transmitter Power (EIRP) 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)
Air Conditioning System
Operating Voltage
28 V DC
Air Conditioning Type
TEC Air Conditioning
Backup Battery
Battery Capacity
12 Ah
Output Voltage
12 V
Battery Type
Lead-acid battery
Battery Life
[5]
>5 hours
Network Access
Ethernet Access
10/100/1000Mbps adaptive Ethernet port
Security Camera (External)
Resolution
1920×1080
Field of View (FOV)
151°
Auxiliary Light
Auxiliary White Light
Security Camera (Internal)
Resolution
1920×1080
Field of View (FOV)
151°
Auxiliary Light
Auxiliary White Light
Lightning Protection
AC Power Port
20 kA (rated value), meets EN 61643-11 Type 2 and IEC 61643-1
Class protection level requirements
Ethernet Port
10 kA (I
total
), meets EN/IEC 61643-21 Category C protection level
requirements
Supported Software
Applications
DJI Pilot 2 (connects to DJI Dock 2 via DJI RC Pro Enterprise for
deployment and commissioning)
Cloud Platform
DJI FlightHub 2 (supported by default)
Third-party cloud platforms (accessed through DJI Cloud API)
Expansion Capability
Open Protocol
DJI Cloud API
Edge computing
Supports data communication with external switches
[1] The actual product weight may vary due to dierences in batch materials and external factors.
[2] The above data does not include the height of the wind speed gauge (145 mm), but includes the height of
the mounting base brackets (55 mm).
[3] When the temperature is below -20° C (-4° F), the aircraft cannot perform ight tasks.
