1. Open the electrical cabinet and power on the dock. Connect the computer to the USB-C port
of the dock.
2. Run DJI Assistant 2 and log in with a DJI account.
3. Select DJI Dock 2, and click the rmware update button on the left.
4. Select the rmware version and click Start Update. The rmware will be downloaded and
updated automatically.
5. The DJI device will restart automatically after the rmware update is complete.
• Make sure the AC power supply of the dock is normal before rmware update. If there
is no AC power supply and the dock is only powered by the backup battery, rmwares
cannot be updated using DJI FlightHub 2 or DJI Assistant 2.
Expansion Ports
The aircraft is equipped with an E-Port that allows access to third-party payloads such as loud
speakers and spotlights. The E-Port lite can be used to connect parachute payloads when the
E-Port is connected to other devices. The dock reserves a space inside the dock cover for storing
the third-party payload, which facilitates the expansion of the aircraft operating capabilities.
• To ensure ight safety, make sure to follow the Payload Development Criteria when
developing PSDK payloads. Visit https://developer.dji.com/payload-sdk/ to view the
documentation and the DJI Enterprise Ecosystem Solution Catalogue to learn more
about the payload development criteria and the recommended payloads.
• The E-Port supports high power output and standard PSDK functions, while the E-Port
Lite only supports a low power output of 5 V and PSDK parachute payloads.
Third-Party Payload Requirements
• Installing a third-party payload will shorten the fight time and reduce the aircraft wind
resistance. Make sure to install the payload as needed.
• The third-party payload should have the protection rating of IP54 or above in order not to
reduce the working stability or the service life of the aircraft.
• The port of the third-party payload connecting to the aircraft should have a water-resistant
rubber ring.
Installation Requirements
• The size of the reserved storage space inside the dock cover is 150 mm × 150 mm × 100 mm
(length×width×height).
• The height of the PSDK payload must not exceed 70 mm.
• After installing the payload, make sure that the third-party payload does not block the
aircraft vision system to avoid aecting the obstacle-sensing performance.
