dji MATRICE 3D Series Flight Manual

DJI Dock 2/Matrice 3D Series Unmanned Aircraft Flight Manual
102
©
2024 DJI All Rights Reserved.
Aircraft
General
Net Weight
[1]
1410 g
Max Takeo Weight
1610 g
Dimensions
335×398×153 mm (L×W×H, without propellers)
Wheelbase
Diagonal Wheelbase: 463.2 mm
Left-Right Wheelbase: 359.9 mm
Front-Rear Wheelbase: 291.4 mm
Max Ascent Speed
6 m/s (Normal mode)
8 m/s (Sport mode)
Max Descent Speed 6 m/s (Normal mode)
6 m/s (Sport mode)
Max Horizontal
Speed
(at sea level, no wind)
Normal Mode, With Obstacle Sensing Enabled: 15 m/s ying forward,
12 m/s ying backward, 10 m/s ying sideways
Sport Mode: 21 m/s ying forward, 18 m/s ying backward, 16 m/s
ying sideways
Max Wind Speed
Resistance
During Operation: 12 m/s
During Takeo/Landing: 8 m/s
Max Take-o Altitude
4000 m
Max Flight Time
[2]
50 minutes
Max Hovering Time
[3]
40 minutes
Max Operating
Radius
[4]
10 km
Max Flight Distance
[5]
43 km
Max Pitch Angle
25° (Normal mode)
25° (Sport mode)
Max Angular Velocity
250°/s
Global Navigation
Satellite System
GPS + Galileo + BeiDou + GLONASS (GLONASS is supported only when
the RTK module is enabled.)
Hovering Accuracy
Range (windless or
breezy)
Vertical:
±0.1 m (with vision positioning)
±0.5 m (with GNSS positioning)
±0.1 m (with RTK positioning)
Horizontal:
±0.3 m (with vision positioning)
±0.5 m (with GNSS positioning)
±0.1 m (with RTK positioning)
Operating
Temperature
-20° to 45° C (-4° to 113° F)
