dji MATRICE 3D Series Flight Manual

DJI Dock 2/Matrice 3D Series Unmanned Aircraft Flight Manual
©
2024 DJI All Rights Reserved.
99
Supplements
This chapter introduces the specifications of the whole system, additional functions of the
aircraft, the operation of optional equipment, and other relevant information.
Specications
Dock
General
Product Name
DJI Dock 2
Total Weight
[1]
34 kg (without aircraft)
Dimensions
[2]
Dock Cover Opened: 1228×583×412 mm (L×W×H)
Dock Cover Closed: 570×583×465 mm (L×W×H)
Input Voltage
100-240 V (AC), 50/60 Hz
Input Power
Max. 1000 W
Operating Temperature
[3]
-25° to 45° C (-13° to 113° F)
Ingress Protection Rating
IP55
Number of Drones
Accommodated
1
Max Allowable Landing
Wind Speed
8 m/s
Max Operating Altitude
4000 m
Receiving Frequency of
RTK Base Station Satellite
Simultaneously receive:
GPS: L1 C/A, L2
BeiDou2: B1l, B2l, B3l
BeiDou3: B1l, B3l
GLONASS: L1, L2
Galileo: E1, E5B
Positioning Accuracy of
RTK Base Station
Horizontal: 1 cm + 1 ppm (RMS)
Vertical: 2 cm + 1 ppm (RMS)
Charging Performance
Output Voltage
28 V DC
Charging Time
[4]
32 minutes
Video Transmission
Video Transmission
System
O3 Enterprise
Operating Frequency
2.4000-2.4835 GHz
5.725-5.850 GHz
Antennas
Built-in 4 antennas, 2T4R, supports intelligent switching
