DJI Dock 2/Matrice 3D Series Unmanned Aircraft Flight Manual
104
©
2024 DJI All Rights Reserved.
Lens Defogging
The tele camera supports lens defogging.
ISO Range
100-6400
100-25600
Shutter Speed
Electronic Shutter: 8-1/8000 s
Max Image Size
4000×3000
Photo format
JPEG
Video Format
MP4 (MPEG-4 AVC/H.264)
Still Photography
Modes
Single: 12 MP
Timed: 12 MP, 0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Low-Light: 12 MP
Video Resolution
H.264
4K: 3840×2160@30fps
FHD: 1920×1080@30fps
Video Bitrate
4K: 130Mbps
FHD: 70 Mbps
4K: 85 Mbps
FHD: 30 Mbps
Digital Zoom
8× (56× hybrid zoom)
Infrared Camera (DJI Matrice 3TD)
Thermal Imager
Uncooled VOx Microbolometer
Pixel Pitch
12 μm
Frame Rate
30 Hz
Lens
[7]
FOV: 61°
Format Equivalent: 40mm
Aperture: f/1.0
Focus: 5 m to ∞
Sensitivity
≤50 mk@F1.0
Temperature
Measurement
Method
Spot Measurement, Area
Measurement
Temperature
Measurement Range
-20° to 150° C (-4° to 302° F, High Gain Mode)
0° to 500° C (32° to 932° F, Low Gain Mode)
Palette White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/
Rainbow 1/Rainbow 2
Photo format
JPEG (8-bit)
R-JPEG (16-bit)
Video Resolution Normal Mode: 640×512@30fps
UHR Infrared Image Mode: 1280×1024@30fps (With the UHR Infrared
Image function enabled, the aircraft can automatically enable or
disable UHR Infrared Image mode according to the ambient light
brightness.)
Video Bitrate
6 Mbps
