DJI Dock 2/Matrice 3D Series Unmanned Aircraft Flight Manual
62
©
2024 DJI All Rights Reserved.
will take o from and land at the dock. It is recommended to install a protective fence so that
unauthorized personnel cannot enter the area where the dock is installed. Make sure that no
flight plan is performed on DJI FlightHub 2 and that the aircraft has landed inside the dock
before entering the protective fence when operating the dock on site. After entering the area,
make sure to press the emergency stop button of the dock.
During a ight task, the aircraft should be more than 10 m away from users to ensure safety.
>1.0 m
0.47 m
>0.6 m
>0.6 m
>0.6 m
>0.6 m
>1.8 m
• If it is necessary to take off and land the aircraft using the remote controller, the
aircraft should be more than 10 m away from operator to ensure safety. Maintain
visual line of sight with the aircraft at all times.
