DJI Dock 2/Matrice 3D Series Unmanned Aircraft Flight Manual

Charging Mode

Charging Mode can be set as Schedule or Standby in DJI FlightHub 2. When the dock is in idle

status, the battery level and the temperature inside the dock can be automatically modified

to meet dierent scenarios. Two hours before a Timed ight task, the dock will automatically

charge the batteries and the ight task will be performed after charging is completed.

Schedule mode is suitable for performing regular tasks such as patrol inspections. The battery

will be charged between 55% and 60% when no task is distributed.

Standby mode is suitable for performing urgent tasks such as re rescue. The battery will be

charged between 85% and 90% when no task is distributed.

Switching charging modes: Open the DJI FlightHub 2 project page, click > , and then Action

to switch to dierent charging modes.

• Battery level may be low under Schedule mode. If the Plan Timer is selected as

Immediate, Low Battery RTH may be triggered during the ight task.

• Maintaining a high power level in Standby mode will affect battery life. It is

recommended to select Schedule mode if the scenario is not urgent.

Using the Charging Kit

When the battery is not inserted into the aircraft, it can be charged using the charging kit (sold

separately). Follow the steps below to charge the battery:

1. Insert the Intelligent Flight Battery into the battery port. Connect the charging base to a

power outlet (100-240 VAC, 50/60 Hz) using the DJI USB-C Power Adapter (100W).

2. Refer to the Status LED Descriptions for more information about the blinking patterns of the

status LED.

3. Disconnect the Intelligent Flight Battery from the charging base when charging is complete.
