64 XR150/XR350/XR550 User Guide Appendix B
Bypass Zones Browser
Access the User Menu.
Press COMMAND to
display BYPASS ZONES.
Press any SELECT key/area.
Press either of the two
left SELECT keys/areas.
When the area where the
zone is located displays,
press any SELECT key/area.
This prompt allows you to
search for a zone by area.
Press the COMMAND key
to scroll through the list of areas.
Press the COMMAND
key to scroll through
the zone names list.
When the correct zone
name displays, press
any SELECT key/area.
The display shows the zone
number. SELECT RST to
Reset the zone. SELECT
BYP to Bypass the zone.
The display returns to
the ZONE: prompt
allowing you to enter
another zone number.
BYPASS ZONES?
ZONE: - RST BYP
SELECT AREA . . .
CMD
FRONT OFFICE
SELECT ZONE . . .
CMD
EAST DOOR
ZONE: 012 RST BYP
ZONE: - RST BYP
Zone Monitor Browser
Access the User Menu. Press
COMMAND until ZONE MONITOR?
displays. Press any SELECT key/area.
SELECT NBR .
When the area where the zone is
located displays, press any SELECT
key/area.
Press either of the two left
SELECT keys/areas.
Press the COMMAND key to scroll
through the zone names list.
When the correct
zone name displays,
press any SELECT
key/area.
The display shows
the zone number.
Selecting ADD places
the zone in monitor mode.
Selecting RMV
removes the zone
from monitor mode.
This prompt allows you to search for a
zone by area. Press the COMMAND key
to scroll through the list of areas.
ZONE MONITOR?
ALL NBR
ZONE: - ADD RMV
SELECT AREA . . .
CMD
FRONT OFFICE
SELECT ZONE . . .
CMD
EAST DOOR
ZONE:012 ADD RMV
