68 XR150/XR350/XR550 User Guide Appendix C
Appendix C
Output Groups Browser
Access OUTPUT GROUP: - in the USER
PROFILES? menu. Press any Select key/area.
At this prompt you can scroll through the list of
output group names.
The first output group name displays.
The next output group name displays.
Press any Select key/area and the output group
number displays.
Press COMMAND.
Press COMMAND.
OUTPUT GROUP: -
SELECT GROUP . . .
CMD
OUTSIDE DOORS . . .
CMD
WINDOWS . . .
FRONT OFFICE . . .
Outputs On/Off Browser
OUTPUT DOOR
DOOR: - ON OFF
SELECT DOOR . . .
CMD
OFFICE FRONT DR
DOOR: 128 ON OFF
Access the User Menu. Press the COMMAND
key to display OUTPUTS ON/OFF?. Press the
Select key/area under OUTPUTS or DOOR.
When the door or output you want displays,
press any Select key/area.
Press either of the two left SELECT keys/areas.
The display shows the door or output number.
This prompt allows you to search for a door or
an output. Press the COMMAND key to scroll
through the list of doors or output names.
OUTPUTS ON/OFF?
OUTPUT: - ON OFF
SELECT OUTPUT . . .
OUTPUT:
127 ON OFF
