Digital Monitoring Products XTL/XTLC Programming Guide
18
BELL OPTIONS
Bell Options
9.1
BELL OPTIONS
Bell Options
This section allows you to program the panel bell output functions. If using the
Model 1135 or 1135DB Wireless Siren, the Trip with Panel Bell option should be
selected in the Output Information programming for the siren.
9.2
BELL CUTOFF: 5
Bell Cutoff Time
Enter the maximum time from 1 to 15 minutes that a wireless output remains on. If
the output is manually silenced or the system is disarmed, the cutoff time is reset.
Default is 5.
9.3
BELL TEST NO YES
Automatic Bell Test
When YES is selected, the 1135 wireless siren is turned on for two seconds when all
areas in the system are armed. The Bell Test only occurs when the areas are armed
from a keypad. Arming performed from an Arming zone or remotely from Remote
Link™ does not activate the Bell Test.
Closing Wait operation
When Bell Test is set to YES, the closing wait function also operates. Closing Wait
provides a delay time before a monitored system arms until the panel receives an
acknowledgment of the closing report from the central station receiver. During the
delay, the keypad displays ONE MOMENT . . . Once the closing is acknowledged,
the keypad buzzes for one second and then displays the ALL SYSTEM ON message. If
communication fails, the message LOCAL ALARM ONLY appears.
9.4
BELL OUTPUT: 0
Bell Output
Enter the output number (31-34, 41-44) for an 1116 or 1117 wireless output when
needed to follow the on and off condition of the bell action. Enter 0 (zero) to
disable.
Note: When BELL ACTION below is set to T for Temporal Code 3, this Bell Output
action will be Pulse for wired outputs 1-4, wireless outputs 31-34 and 41-44.
9.5
BELL ACTION . . .
Bell Action
This denes the type of Bell Action from zone alarms that will occur. Trouble
conditions do not activate Bell Action. There are seven zone types you can program
individually for Bell Output. To provide a steady Bell Output, enter S. For a pulsed
output, enter P. For a Temporal Code 3 output, enter T and for no wireless zone,
enter N.
9.5.1
FIRE TYPE: P
Fire
Denes Bell Action for Fire Type Zones. The default is set at P.
9.5.2
BURGLARY TYPE: S
Burglary
Denes Bell Action for Burglary Type Zones. The default is set at S.
9.5.3
SUPRVSRY TYPE: N
Supervisory
Denes Bell Action for Supervisory Type Zones. The default is set at N.
9.5.4
PANIC TYPE: N
Panic
Denes Bell Action for Panic Type Zones. The default is set at N.
9.5.5
EMERGNCY TYPE: N
Emergency
Denes Bell Action for Emergency Type Zones. The default is set at N.
9.5.6
AUXLRY 1 TYPE: N
Auxiliary 1
Denes Bell Action for Auxiliary 1 Type Zones. The default is set at N.
9.5.7
AUXLRY 2 TYPE: N
Auxiliary 2
Denes Bell Action for Auxiliary 2 Type Zones. The default is set at N.
