XTL/XTLC Programming Guide Digital Monitoring Products
21
OUTPUT INFORMATION
Output Information
11.1
OUTPUT INFO
Output Information
This section allows you to program and name wireless outputs into the panel.
11.2
OUTPUT NO: -
Output Number
Enter an output number. Select from the following output numbers:
• 31 to 34 —
Slow response
time
*
wireless outputs (activate within 15 seconds)
• 41 to 44 — Fast response time* wireless outputs (activate within 1 second)
Note: Addresses 31 to 34 and 41 to 44 are available for wireless outputs, wireless
zones, or wireless key fob zones and can only be assigned to one device.
* The response time of a wireless output is the time it takes for a wireless output to
activate once the panel event occurs. You determine whether a wireless output is a
slow or fast response based on the output number assigned. A slow response output
number extends battery life, but response time may be up to 15 seconds. A fast
response output number responds within 1 second, but reduces battery life. Refer
to the specic wireless output installation guide to determine battery life.
11.3
* UNUSED *
Output Name
This section allows you to dene a 16 character alphanumeric name for any wireless
output.
An output that is not part of the system must be marked *UNUSED*. To mark an
output unused, de lete the old name by pressing any Select key, then press the
COMMAND key. The pro grammer auto matically pro grams the name as * UNUSED *.
11.4
SERIAL#: -
Serial Number
Enter the eight-digit serial number found on the wireless device.
ALREADY USED: ZXX
This message displays when the serial number is already programmed for another
output or zone. The programmed output or zone number displays.
11.5
SUPRVSN TIME: 240
Supervision Time
Press any top row key to select the supervision time required for the wireless
output. Press COMMAND to accept the default time. Default is 240 minutes.
0 3 60 240
Select the required number of minutes. The transmitter must check in at least
once during this time or a missing condition is indicated for that zone. 1100 Series
transmitters automatically check in based on the supervision time selected for
the wireless zone, no additional programming is needed. Zero (0) indicates an
unsupervised transmitter.
The 3 minute supervision time is only available if using an 1135 Wireless Siren.
Note: When the panel is reset, a receiver is installed or powered down and powered
up, or programming is complete, the supervision timer restarts for all wireless
outputs.
11.6 Trip with Panel Bell Option
This option displays when the wireless device is an 1135 wireless siren. Select YES to
have the 1135 wireless siren follow the panel bell output. Default is YES.
TRIP WITH PANEL
BELL NO YES
INT PERIM
AREA NO: -
INT BDRM PERIM
* UNUSED *
