INTRODUCTION
1.9 Entering Non-Alpha Characters
To enter a space in an alpha entry, press the 9 digit key followed by the third Select key. The three
characters on the 9 digit key are Y, Z, and space. You can also enter the following characters: – (dash),
. (period), * (asterisk), and # (pound sign) using the 0 (zero) key and the four Select keys from left to
right. For example, to enter a – (dash), press the 0 (zero) key and then the left Select key. A dash now
appears in the keypad display. The table below shows the character locations for DMP keypads.
Key Number Select Key 1 Select Key 2 Select Key 3 Select Key 4
1 A B C (
2 D E F )
3 G H I !
4 J K L ?
5 M N O /
6 P
Q
R &
7 S T U @
8 V W X ,
9 Y Z space _
0 - . * #
1.10 Keypad Displays Current Programming
Each programming prompt displayed at the keypad shows the currently selected option in the panel
memory. These options are either shown as a number, a blank, or a NO or YES. To change a number or
blank to a new number, press any top row Select key. The current option is replaced with a dash. Press
the number(s) on the keypad you want to enter as the new number for that prompt. It is not necessary to
enter numbers with leading zeros. The panel automatically right justies the number when you press the
COMMAND key.
To change a programming prompt that requires a NO or YES response, press the Select key for the
response not selected. See Figure 3.
For example, if the current prompt is selected as YES and you want to change it to NO, press the third
top row Select key. The display changes to NO. Press the COMMAND key to display the next prompt.
THEN
Press the third top row
Select key.
The keypad displays the new
selection. Press CMD to advance.
YESBELL TST
NOBELL TST
Figure 3: Changing the Current Programming Option
