XTL/XTLC Programming Guide Digital Monitoring Products
35
APPENDIX
Exiting the Diagnostics program
Press the COMMAND key until STOP displays. Press any Select key. The keypad returns to the Status List
display.
16.5 Using the 984 Command Function
This feature allows the integrity of the cellular communication to be tested.
NBR: Not available for XTL/XTLC panels. If selected the keypad displays NO DIALER.
TEST: This option tests each function of the panel’s cellular communication. The tests proceed until a
function does not pass, or until all have been tested with positive results. The progress displays during
each test.
PICKUP: Not available for XTL/XTLC panels. If selected the keypad displays NO DIALER.
16.6 Using the Walk Test
The XTL/XTLC panel provides a walk test feature that allows a single technician to test all the protection
devices connected to zones on the system. Conduct the Walk Test within 30 minutes of resetting the
panel. The Walk Test automatically ends if no zones are tripped for 20 minutes. TEST IN PROGRESS
displays at all keypads. When ve minutes remain, TEST END WARNING displays. If any areas are armed
the Walk Test does not start and SYSTEM ARMED displays.
WALK TEST
STD WLS PIR
Walk Test
To conduct the Walk Test, reset the control panel by pressing the reset button then
wait one minute. From the keypad, enter the code 8144. The keypad displays WALK
TEST.
WLS (Wireless Check-in Test) - Select WLS to automatically test 1100 Series wireless
transmitter communications. Includes all wireless devices except key fobs and
transmitters programmed for a supervision time of 0 (zero).
PIR (Wireless PIR Walk Test) - The PIR Walk Test allows the installer to verify the 1126
and 1127 operation. When enabled, the 1126 LED ashes each time motion is detected
for up to 30 minutes. This is a local test only and no messages are sent to the Central
Station.
Trip Counter For DMP Wireless Check-in Test (WLS)
Displays the number of wireless zones that automatically communicate a supervisory
check-in message.
•The number of zones that check in. (XX in the example).
•The total number of wireless zones programmed for supervision that should
check in. (ZZ in the example).
END - Select END to stop the Wireless Check-in Test. When the test ends or
a 20-minute time-out expires, normal wireless zone processing returns. If all
transmitters check-in, both numbers will match within three (3) minutes. If a
transmitter has multiple zones (1101, 1114, etc.), all zones will be included in the
counts. Failed wireless zones then display on the keypad.
TEST END WARNING
Test End Warning
When no zones have been tripped and ve minutes remain on the 20 minute Walk Test
timer, the keypad displays TEST END WARNING and the keypad tones. If no additional
test zone trips occur, the test ends and a nal Sensor Reset automatically occurs. The
System Test End message is sent to the receiver along with Verify and Fail messages for
each zone under WALK test. Faulted zones then display on the keypad.
SOUTH LOBBY
ZONE: 10 -FAIL
Failed Zones Display
Each zone that did not trip at least once during the Walk Test displays on the keypad
that initiated the test. Any Fire (FI) Panic (PN) or Supervisory (SV) 24-hour zone that is
faulted at the end of the Walk Test displays a trouble condition for that zone regardless
of the message programmed for the open or short condition of the zone and a zone
trouble is sent to the receiver. Press the COMMAND key to display the next failed zone.
For the Wireless Check-in Test, failed wireless zones display only on the keypad.
Zone Verify/Fail reports are not sent to the central station receiver for the wireless
checkin test.
WALK TEST
TRIPS: XXX END
