XTL/XTLC Programming Guide Digital Monitoring Products
27
ZONE INFORMATION
To operate arming and disarming properly, the Key Fob should be assigned to a User Number with
appropriate area assignments, however, the User Number does not have to exist at the time the Key
Fob is programmed. The User Number can be added at the User Menu later by the User.
The following programming continues from when Key Fob YES is selected.
13.11.1
KF USER NO:
Key Fob User Number
Enter the User Number used to identify the key fob user and their arming and
disarming authority. Default is blank.
— User number range: 1 to 30
NOT IN USE
Displays when the User Number entered does not exist in User Code programming.
The key fob can be added, but the user must eventually be added to cause the key
fob to operate.
13.11.2
SERIAL #: -
Key Fob Serial Number
Enter the eight-digit serial number found on the wireless device.
ALREADY USED Zxx
Displays when the serial number is already programmed. The programmed zone
number displays.
13.11.3
SUPRVSN TIME: 0
Key Fob Supervision Time
Press any top row key to select the supervision time required for the key fob zone.
Press COMMAND to accept the default time. Default is 0.
0 60 240
Press the Select key under the required number of minutes. The key fob must check
in at least once during this time or a missing condition is indicated for that zone.
1100 Series key fobs automatically checkin based on the supervision time selected
for the wireless zone, no additional programming is needed. Zero (0) indicates an
unsupervised transmitter.
Note: When the panel is reset or a receiver is installed or powered down and
powered up, the supervision timer restarts for all wireless zones.
13.11.4
BUTTONS: 4
Number of Key Fob Buttons
Enter the number of buttons (1, 2, or 4) on the key fob being programmed. Default
is four buttons.
Note: If the key fob is a one-button model, programming continues at the Button
Action section. Default button assignment for one-button key fobs is a Panic Alarm
(PN) with no output assigned.
13.11 .5
TOP BTM LFT RGT
Key Fob Button Selection (Four Buttons)
This prompt only displays if the key fob being programmed is a four-button model.
Press the Select key under the key fob button to program. The following list
identies the default button assignments:
TOP Arming with areas 1, 2, and 3 assigned
BTM Disarming with areas 1, 2, and 3 assigned
LFT Panic Alarm (PN) with no output assigned
RGT Arming with Area 1 assigned
13.11 .6
TOP BTM
Key Fob Button Selection (Two Buttons)
This prompt only displays if the key fob being programmed is a two-button model.
Press the Select key under the key fob button to program. The following list
identies the default button assignments:
TOP Arming with areas 1, 2, and 3 assigned
BTM Disarming with areas 1, 2, and 3 assigned
12.11 .7
ACTION: XXXXXXX
Button Action
This option species the Button Action for an individual key fob button. The default
action for the button selected is displayed. Press any Select key to display the
Button Action options. To view more options press the COMMAND key.
