Digital Monitoring Products XTL/XTLC Programming Guide
38
16.9 Zone Type Defaults
The XTL/XTLC panel contains 11 default zone types that provide the most commonly selected functions
for their applications. All zone types can be customized by changing the variable options listed below.
Key Fob - Indicates if a DMP key fob is programmed.
Type - These are the abbreviations displayed on the keypad for the zone types.
Area - For a ALL/PERIM or HOME/SLEEP/AWAY system, this is either Interior, Bedroom, or Perimeter. For
an AREA system use 1 to 6.
Wireless - 1100 Series Wireless options.
Contact - Indicates if the Universal Transmitter is programmed to use the internal or external contact.
External Contact N/O? - Identies whether externally installed contacts are programmed as a normally
open (N/O) or normally closed (N/C) circuit. Y = N/O Contacts. N = N/C Contacts.
1114 Contact - Indicates if the 1114 Zone Expander is programmed for contact(s) 1, 2, 3, or 4.
Supervision Time - Selects the number of minutes for DMP wireless supervision.
1142 LED Operation - Identies DMP 1142 Wireless Two-Button transmitter LED operation.
Disarm/Disable - Disables zone tripped messages from 1103 Transmitters and 1126/1127 PIRs while
disarmed.
PIR Pulse Count - Selects the number of pulse counts the 1126/1127 uses before sending a short
message.
Sensitivity - Sets sensitivity for the 1126/1127 PIR.
Message - A = alarm report, T = trouble report,
L = local with no report, — (dash) = no report.
Output - 31 to 34 and 41 to 44 wireless outputs or wireless key fob zones.
Action - This selects the type of relay output:
S = steady, P = pulse, M = momentary, and F = follow
Swinger Bypass - The zone can be automatically bypassed after a programmed number of trips.
Prewarn - This selects the keypad address that sounds the entry prewarn for this zone.
Entry Delay - Selects the entry delay timer used for this zone.
Priority - Requires this zone to be in a normal condition before the area can be armed.
TrafcCount- Provides the number of zone trips per area for Night and Exit type zones in a disarmed
state.
Zone Audit Days - Number of days allowed to elapse without a zone being tripped before a message is sent.
Receiver Routing - This selects the routing option for Auxiliary 1 or Auxiliary 2 zone types.
Style - The abbreviations that display on the keypad for arming zone style. TGL = Toggle,
ARM = Arm only, DIS = Disarm only,
STEP = Wireless arming, MNT = Maintain
