XTL/XTLC Programming Guide Digital Monitoring Products
25
ZONE INFORMATION
13.7.1
STYLE: TOGGLE
Style
This option species the style for the arming/disarming operation. The default for
STYLE: is TGL (toggle). Pressing any Select key displays the STYLE options. To view
more style options press the command key. The following is a description of the
action for each option condition.
TGL ARM DIS STEP
TGL (Toggle) - When the zone changes from normal to shorted, the programmed
areas toggle between the armed or disarmed condition. When restored to normal, no
action occurs. When the zone is opened from a normal (disarmed) state, a trouble is
reported. When opened from a shorted (armed) state, an alarm is reported and the
zone is disabled until you disarm the area(s) from either a keypad or Remote Link™
computer.
ARM - When the zone is shorted, the programmed areas are armed. When restored to
normal, no action occurs. When the zone is opened from a normal (disarmed) state, a
trouble is reported. When opened from a shorted (armed) state, an alarm is reported.
DIS (Disarm) - When programmed as an Area system, a short will disarm the
programmed areas. When programmed as a ALL/PERIM or HOME/AWAY system, a
short will disarm ALL areas. When restored to normal, no action occurs. When the
zone is opened from a normal (disarmed) state, a trouble is reported.
STEP - When programmed as an area system, a short will arm the areas and beep
the keypads once. When programmed as ALL/PERIM or HOME/AWAY, on the rst
short HOME will arm and beep the keypad once. On the second short, SLEEP will arm
and beep the keypads twice. On the third short, AWAY will arm and beep the keypad
three times. A normal condition will cause no action. An open condition will disarm
the programmed areas and beep the keypads for one second.
Note: This arming style is designed for wireless arming pendants. When using a
arming/disarming keyswitch, locate the keyswitch within the protected area.
MNT
MNT
(Maintain) - When the zone is shorted, the programmed areas are armed.
When restored to normal, the programmed areas are disarmed and any alarm bells
are silenced. When the zone is opened from a normal (disarmed) state, a trouble
is reported. If opened from a shorted (armed) state, an alarm is reported and the
zone is disabled until you disarm the area(s) from either a keypad or Remote Link™
computer.
DMP Wireless
For an 1100 Series Key Fob see the 1100 Series Wireless Key Fob programming section.
NOTE: All wireless programming is stored in the XTL/XTLC panel. Each time the panel powers up, when
the programmer STOP routine is selected or the panel is reset, the wireless receiver memory refresh could
take up to 45 seconds to complete depending on the number of wireless zones programmed and the Red
LED remains on during this time. Normal wireless receiver operation is inhibited during the memory refresh
period.
13.9
SERIAL #: -
Serial Number Entry
Enter the eight digit serial number, including leading zeros, found on the wireless
device.
13.10
CONTACT: INTERNAL
Contact
This option displays if the serial number entered is for an 1101, 1103, or 1105
Universal Transmitter or 1114 Wireless Four-Zone Expander. Press any top row key to
select the contact.
INT EXT
This option displays when programming an 1101, 1103, or 1105 Universal
Transmitter. Select INT to use the internal reed switch contacts. Select EXT to
connect an external device to the 1101, 1103, or 1105 terminal block. Default is
INTERNAL.
By allowing both of the transmitter contacts (INT and EXT) to be used at the same
time, two zones may be programmed from one transmitter. When using multiple
contacts, you must use consecutive zone numbers.
For example, program transmitter serial number 01345678 as Zone 11 with an INT
contact type and Zone 12 with an EXT contact type. The same serial number is used
for both zones.
To Next Page
