XTL/XTLC Programming Guide Digital Monitoring Products
31
ZONE INFORMATION
If no other cross-zoned zone in the system trips before the cross-zone time expires,
the panel sends only a fault report from the rst zone to the receiver.
Note: If CRS ZONE is YES, a valid CRS ZN TIME must be programmed in System
Options for this feature to be enabled.
Cross-zoning is not compatible and cannot be enabled for Fire Verify zone
types.
13.18
PRIORITY NO YES
Priority
Selecting YES allows you to provide additional protection for a zone by requiring it
to be in a normal condition before its assigned area can be armed. A priority zone
cannot be bypassed.
A Priority zone not in a normal condition cannot be armed. If a user attempts to arm
the area, the keypad displays the bad zone name followed by PRIORITY ZONE and
the arming is stopped.
13.19
TRAFFIC COUNT
TrafcCount
This option is displayed for NT or EX type zones. Select YES to provide reporting
to the receiver of the number of zone trips while in a disarmed state. The number
of trips for each zone set as trafc count are added together and included with
the area closing message and reported to the central station automation system.
Default is NO.
13.20
ZONE AUDIT DAYS:
Zone Audit Days
Enter the number of days (0 to 99) allowed to elapse without the zone being tripped
before a fault message is sent. The message is sent to the receiver(s) programmed
to receive Supervisory/Trouble Reports at 10:00 am following the expiration of
the timer. Each time the zone is tripped, the Zone Audit Days timer restarts and
begins to countdown the number of days programmed. After the countdown expires,
a fault message is sent and the Zone Audit Days timer restarts and begins to
countdown the number of days programmed. Available for all zone types except re
and re verify. Enter 0 (zero) to disable this function. Default is 0 (zero).
13.21
RECEIVER ROUTING
Receiver Routing
This option displays if Zone Type is set for Auxiliary 1 or Auxiliary 2.
Press any top row key to select the Receiver Routing for the selected zone.
• Select NORM to send Alarm and Supv/Trbl messages from this zone to receiver 1
or receiver 2 as programmed within the receiver.
• Select 1 to send Alarm and Supv/Trbl messages from this zone to receiver 1
only, regardless of the programming for that receiver.
• Select 2 to send Alarm and Supv/Trbl messages from this zone to receiver 2
only, regardless of the programming for that receiver.
• Select BOTH to send Alarm and Supv/Trbl messages from this zone to both
receivers, regardless of the programming for either receiver.
13.22
ZONE NO: -
Zone Number
Enter the zone number you want to program next. Return to section 11.1 and follow
the descriptions of each programming prompt. If all zones are programmed, press
the ARROW key at the ZONE NO: – display to continue.
