System Errors
4-16 72A-2337-01 Rev. B 11/05
NOTE1 Some system errors cannot be cleared. For example, if the Instrument has no Analog
Multiplexer board, the error condition remains until the board is supplied. If any of the fuses on
any of the Amplifier boards are blown, the F6300 will not be operational. Visually inspect the
Amplifier fuses to ensure that the fuses are functional.
Over Tem-
perature or
fuse blown
(I AMP #8)
Amplifier in slot 9 is overheated or has a blown
fuse.
Replace the amplifier
board in slot 9.*
Over Tem-
perature or
fuse blown
(I AMP #9)
Amplifier in slot 10 is overheated or has a
blown fuse.
Replace the amplifier
board in slot 10.*
Missing
analog mul
-
tiplexer
board
Hardware is missing or not communicating
properly with the
CPU.
Check the communication
cable. If OK, replace the
analog multiplexer board
in slot 4.*
Control
Panel Mode
Option F6909 required. Call Doble Customer Ser-
vice.
Macro
Mode
Option F6910 required. Call Doble Customer Ser-
vice.
* Refer to Chapter 5 ”Field Replacement Procedures” when replacing any boards.
Table 4.6 System Error Resolution (Continued)
To Next Page
