72A-2337-01 Rev. B 11/05 E-1
Appendix E. F6300 Specifications
Current Sources
Table E.1 Source Configurations
Output Power
Continuous
Output Power Transient
for 1.5 Sec.
6*150 VA sources 6*225 VA sources
2*450 VA sources 2*675 VA sources
Ranges and Resolution
Table E.2 150 VA Sources
Current Range (Resolution)
AC
1.5 Seconds
Transient
Continuous
15, 30 A (0.001 A), 60 A rms (0.01 A)
7.5, 15 A (0.001 A), 30 A rms (0.01 A)
DC
1.5 Seconds
Transient
Continuous
10, 20, 40, ADC (0.01 A)
5A (0.001 A), 10, 20 ADC (0.01 A)
NOTE Three 150 VA current sources can be combined into one 450 VA current source.
