Table C.1 Maximum Compliance Voltage for Current Source
Combinations
Current
Range
150 VA
Source
450 VA
Source
7.5 A 20 V 60 V
15 A 10 V —
22.5 A — 20 V
30 A 5 V —
45 A — 10 V
90 A — 5 V
Table C.2 Maximum Compliance Voltage for Transient
Current Source Combinations
Current
Range
225 VA
Source
675 VA
Source
15 A 15 V 45 V
30 A 7.5 V —
45 A — 15 V
60 A 3.75 V —
90 A — 7.5 V
180 A — 3.75 V
Compliance Voltage and Current Range
