F6300 Power System Simulator User Guide
72A-2337-01 Rev. B 11/05 E-3
NOTE All specifications are subject to change without notice.
Phase Angle • Range: 0
o
to +359.9
o
(Lead)/0 to −359.9
o
(Lag)
• Accuracy: ±0.25
o
at 50/60 Hz
• Resolution: ±0.1
o
at 50/60 Hz
Frequency Bandwidth: DC to 3 kHz at full power for transient playback.
Range: DC, AC from 0.1 Hz to 2 kHz at full power, continuous load.
Resolution: 0.001 Hz
Accuracy:
• 0.05 PPM:Typical
• 1.5 PPM: 20° to 30° C
• 10 PPM: 0° to 50° C
Ramp/Set Ramp: Increments/decrements voltage, current, phase angle, and fre-
quency at user defined ramp rates. Ensures smooth, linear changes
in value.
Input Power
Supply
• 115 V nominal at 15 A maximum (50 or 60 Hz)
• 230 V nominal at 10 A maximum (50 or 60 Hz)
Temperature • Operating temperature: 0° to 50° C (32° to 122° F)
• Storage temperature: -25° to +70° C (13° to 117° F)
Humidity Up to 95% relative humidity, non-condensing
Interfaces RS-232 or Ethernet remote control to computer
Safety European Standard:
• EN61010-1:1993/A1+A2
• EN61010-2-031:1994
Electromagnetic
Compatibility
(EMC)
European Standard:
• EN61326:1997/A1:1998
• US Standard:
• FCC 47CFR Part 15 Class A
Enclosure High impact, molded, flame retardant ABS. Meets National Safe Transit
Association testing specification No. 1A for immunity to severe shock
and vibration.
Dimensions and
Weight
• Dimensions: 15 x 9.5 x 18 in or 38 x 24 x 45.7 cm
• Weight: 35.4 lbs/16.1 kgs
Table E.4 General Specifications (Continued)
Specification Description
