CT100 inverter Function parameters
73
Function
code
Name
Detailed instruction of
parameters
Min. unit
Default
value
Modify
No.
13: specified count value
arrival
14: simple PLC stage is
completed
15: simple PLC cycle is
completed
16: running time arrival
17～20: reserved
F07.05
AO1 output
0: running frequency
1: ramp reference
2: set frequency
3: rotating speed
4: output current
5: output voltage
6: output power
7: output torque
8: set torque
9: potentiometer
10: AI1
11: AI2
12: pulse frequency HDI
1
0
○
F07.06
AO2 output
1
0
○
F07.07
HDO open
collector
high-speed
pulse output
1
0
○
F07.08
Corresponding
setting of AO1
output lower
limit
0.0%～100.0%
0.1%
0.0%
○
F07.09
AO1 output
voltage
(current) lower
limit
0.00V～F07.11
0.01V
0.00V
○
F07.10
Corresponding
setting of AO1
output upper
limit
0.0%～100.0%
0.1%
100.0%
○
