CT100 inverter Function parameters
74
Function
code
Name
Detailed instruction of
parameters
Min. unit
Default
value
Modify
No.
F07.11
AO1 output
voltage
(current) upper
limit
F07.09～10.00V
0.01V
10.00V
○
F07.12
Corresponding
setting of AO2
output lower
limit
0.0%～100.0%
0.1%
0.0%
○
F07.13
AO2 output
voltage
(current) lower
limit
0.00V～F07.15
0.01V
0.00V
○
F07.14
Corresponding
setting of AO2
output upper
limit
0.0%～100.0%
0.1%
100.0%
○
F07.15
AO2 output
voltage
(current) upper
limit
F07.13～10.00V
0.01V
10.00V
○
F07.16
Corresponding
setting of HDO
output lower
limit
0.00%～100.0%
0.1%
0.00%
○
F07.17
HDO output
lower limit
0.00kHz～F07.19
0.01kHz
0.00kHz
○
F07.18
Corresponding
setting of HDO
output upper
limit
0.00%～100.0%
0.1%
100.0%
○
F07.19
HDO output
upper limit
F07.17～50.00kHz
0.01kHz
50.00kHz
○
F08 Group Fault and protection
