D439E Service Manual 2. Engine Mechanical System (D439E)
84
e. Tighten the connecting rod cap with specified
torque.
Tightening torque : 29.4 Nm + 90°
(3.0 kgf.m + 90°, 21.8 Ib-ft + 90°)
6. Install rear oil seal slinger using the special tool
(09211-41000).
7. Apply the sealant (Loctite #5699) to the rear oil
seal, and then install the rear oil seal (1).
8. Install the oil strainer (1).
9. Install the oil pan (1).
To Next Page
