Doosan DVF5000 - Page 27

25
4. Machine Power-up
④ From among two cables wound around the oil cooler, find the temperature detection
sensor cable and connect the cable into the connector removed inside the machine
splash guard.
⑤ Find the “OJP” and “OJT” hoses and attach them to the hydrau
lic connector on the
oil cooler.
“OJP”
“OJT ”
Censor
Cable
Connector
