3. Machine Anchoring Operation
3.2 Machine Anchoring Operation
1) Items to be prepared for anchoring
For the anchoring required to secure the machine on the factory floor, first prepare the
various parts and other essentials.
① Hammer Drill
② Hammer drill bit for making a hole with a diameter of 22mm and a
more.
③ Manual dispenser for injecting the chemical anchor and chemical.
④ Various anchor parts shipped with the machine (Clamp Bolt, Z-Clamp, Screw Jack,
etc.) and a marker for marking the location of the anchor hole on the floor.
⑤ Vacuum cleaner for removing concrete dust generated during anchor drilling and an
air gun with a long spout for cleaning the inside of the hole.
Chemical anchor and manual
dispenser
Various anchor parts and
Marker (pen)
Manual
dispenser for
chemical
