Doosan DVF5000 - X Axis Movement Straightness

39
6. Machine Accuracy Measurement and Adjustment
0.010/300
0.015/300
0.010/300
0.010/300
0.020/500
0.020/300
0.020/300
0.020/300
0.020/300
Checking of
squareness
between X-axis
motion and
the Y-axis
motion
(XY 상호직각도)
Checking of
squareness
between
Spindle center
line and
X-axis motion
(주축중심선과
X축운동 직각
도)
Checking of
squareness
between
Spindle center
line and
Y-axis motion
(주축중심선과
Y축운동 직각도)
Checking of
squareness
between C-axis
center line and
X-axis motion
(C축중심선과
X축운동 직각
도)
Checking of
squareness
between C-axis
center line and
Y-axis motion
(C축중심선과
Y축운동 직각도)
XZ plane
(XZ평면)
YZ plane
(YZ평면)
7
8
9
XZ plane
(XZ평면)
YZ plane
(YZ평면)
10
ISO
DOOSAN
3/6
NO.
Item (검사 항목)
Diagram (측정 방법)
Tolerance (허용 공차)
Result
(측정 결과)
GEOMETRICAL TEST (기하학적 정밀도)
Squareness (직각도)
Unit : mm
6
XY plane
(XY평면)
0.010/300
Y
X
X
Y
X
Y
