8. ATC Alignment and Finishing Operation
Coolant Hoses
① Flood Coolant Hose Connection
② T.S.C Coolant Hose Connection
Once the coolant tank is in position, tighten the coolant tank fixing bolts until they touch
the floor in order to secure the tank.
▪ If the surface of the floor is uneven, and if the fixing bolts do not touch the floor due to
their short length, use a block.
Coolant
To Next Page
