Dormakaba c-lever pro User Manual

Product description Technical Manual
14 HAC Standard fixing - 02/2018dormakaba c-lever pro
3.3 Scope of delivery
• 1 inside unit • 1 antenna cable
• 1 external fitting • 2 batteries, AA lithium
• 1 coupling unit • 1 drilling template
• 1 direction pin • Screws and elongations depending on
variant
• 1 spindle • Crimping tool (option)
• 1 inside lever handle • Adapter for programmer 1355-42B (op-
tion)
• 1 outside lever handle
Overview of backplates
The backplates of the internal fitting are the same as the ones for the external fitting. “Nar-
row-wide variant”: The backplates of the internal fitting and the external fitting are different.
1 2 3 4 65 7 8
Item Backplate designation
(profile hole measurement in mm)
1 PZ 98 / SK 105
2* PZ 85, 88, 90, 92
RZ 94
AU 90
3 PZ 70, 72, 78
RZ 74, 78
4 Blind
5 PZ 98,
SK 105
6* PZ 85, 88, 90, 92
RZ 94
7 PZ 70, 72R, 78
RZ74, 78
8 Blind
* *Version described in this document
